MONITOR |
- 5.7" (145mm) mono display with
320 x 240 resolution
- Optional 6.5" (165mm) color display with
640 x 480 resolution
|
KEYPAD |
- Encrypting PIN Pad (EPP) to comply with International encryption standards
- Triple DES compliant
- Optional metal EPP
|
PRINTER |
- 3 1/8" (80mm) thermal printer with presenter
|
CASH DISPENSER |
- Dispenses 2.5 notes per second
|
CARD READER |
- Dip-style card reader
- Optional dip EMV smart card reader, EMV motorized card reader (Track 1,2,3 Read), or EMV motorized card reader/encoder (Track 1,2,3 Read, Track 3 Write)
|
SECURITY |
- UL 291 Business Hours Service cabinet or optional UL 291 Level 1 safe
- Manual lock
- Optional Electronic lock or Kaba® Mas Cencon lock
|
COMMUNICATION |
- Dial-up, TCP/IP or wireless communications optional
|
VOICE GUIDANCE |
- Americans with Disability Act (ADA) compliant
|
HARDWARE |
- PC-based Intel® XScale 32-bit processor
- 64MB RAM expandable to 256MB
- 2MB journal storage (32,768 record)
- One USB Slave port
- Four USB master port
- Two PC Card slots
- Five serial ports
|
OPERATING ENVIRONMENT |
- Environment Temperature Range :
- Vault/Electronics: 50F - 104F
- External: -30F - 122F
- Relative Humidity: Non-condensing - 20% - 80%
- Power Consumption: 2.0A @ 115 VAC @ 60 Hz
1.0A @ 230 VAC @ 50 Hz
|
DIMENSIONS |
- Height: 63.6"
- Width: 20.5" Vault;
22.4" Sleeve
- Depth: 29.7" for walls as thick as 11"
- Weight: 275 lbs
|
