"PRIMARY FUNCTION ATM FOR VESTIBULE, THROUGH THE WALL WALK UP AND DRIVE UP LOCATIONS, DELIVERING TARGETED ACCOUNT SERVICES FROM A COMPACT, SECURE FOOTPRINT"

The Personas M Series 87 is a primary function ATM for exterior locations, delivering targeted account services to your customers at their convenience.

NCR's Personas M Series brings to market a set of flexible, upgradeable and configurable ATMs designed on a single platform. The Personas M Series 87 offers a wide range of cash, deposit and account based transactions from a secure, compact footprint making it the ATM of choice to deliver dedicated account services in vestibule and through-the-wall locations.

Configuration options on the Personas M Series 87 include cash accept, cash dispense, cheque accept, coin dispense, bill payment, statement print and/or passbook update. This ATM enables you to deliver a targeted set of account services to your customers any time, any place. The Personas M Series 87 improves the efficiency of your self-service channel by reducing your costs even further.

NCR's evolutionary design is evident at every level of the Personas M Series 87. The compact user interface is easy to use, integrated advertising panels and large display allow you to promote your products, your brand and offers third party advertising opportunities. Designed to fit your existing through-the-wall aperture, the Personas M Series 87 removes the need for costly re-building work and lets you reuse advertising surrounds.

NCR aims to protect your investment through world-class usability and design and our continual investment in technological advancements. The flexible nature of the Personas M Series lets you introduce new functionality and keep pace with the changing business environment. The Personas M Series offers a high level of security and standards compliance. This includes countermeasures to ATM fraud, support for EMV, Triple DES and Remote Key Management and public and private audio.

PERSONAS M 87 Specifications:

MONITOR
  • 12.1" SVGA sunlight readable colour LCD with autoscaling capability
  • Optional display privacy filter
  • Optional interior and exterior touchscreen
  • 8 Tactile function display keys
KEYPAD
  • Rugged tactile 16 key
  • Secure EPP (Encrypting PIN Pad)
  • Triple DES compliant
  • Remote Key Management Certification as meeting the requirements of ISO
  • Optional alphanumeric keyboard
PRINTER
  • Receipt printer 40 column graphics thermal printer
  • Optional sideways feature allows 80 column x 20 row mini-statement
  • Journal printer 40 column graphics thermal printer
  • STATEMENT PRINTER
    • 80 column letter quality thermal printer with document capture
    • Optional full graphics
    • Optional 4" bunching capability
  • PASSBOOK PRINTER
    • Page-turning passbook feature for horizontally stitched books
    • Combined statement and passbook printer with document capture
CASH DISPENSER
  • 2, 3 or 4 denomination options with bunch, retract and purge capability
  • NCR multimedia cassette with 11.6" capacity
  • Optional tamper indicating cassettes
  • Optional coin dispense
CARD READER
  • DIP
  • Smart DIP: supports smart card
  • IMCRW (Integrated Motorized Card Reader Writer): option to support smart cards
  • CROPF (Card Return on Power Fail)
  • Optional barcode reader
CASH ACCEPTOR
  • Accepts and validates up to 100 notes per transaction
  • Up to 50 note denominations per template including polymer
  • Storage up to 3,400 notes
  • Returns notes held in escrow if transaction cancelled by customer
  • Proof of deposit with cash totals via ATM receipt
iTRAN 1000 CHECK PROCESSOR
  • Cheque and credit slip processing
  • True MICR read of E13B or CMC7 code line
  • High quality front and rear imaging of documents
  • Rear endorsement printing either single line or multi-line
  • Optional CAR/CAV/LAR
  • Separate enclosures for cash and cheques
  • Proof of deposit with cheque image via ATM receipt
SECURITY
  • UL 291 Level 1
  • CEN Grade 3
  • CEN Grade 4
COMMUNICATION
  • Dial-up and TCP/IP connectivity solution
SOFTWARE
  • Microsoft® Windows® XP
  • APTRATM™ software suite
    • Performs Remote Diagnostics
    • Receives & Archives Journals
    • Graphic Images & Video clips transfer
    • Software upgrades downloads
HARDWARE
  • Intel® Penitum® 3 or 4
  • optional CD or DVD ROM
  • optional NTSC, PAL or third party camera
OPERATING ENVIRONMENT
  • Environmental:
              Level 1 dust filtration
              Optional Level 2 dust filtration
              Optional Level 3 dust filtration
  • Environment Temperature Range:
              -31F - 122F
  • Relative Humidity:
    Non-condensing - 10% - 100%
DIMENSIONS
  • Height: 53.4"
  • Width:
              25.2"
              27.2" with iTRAN 1000
  • Depth:
              32.9" for UL safe
              34.2" for CEN safe
              15.5" for Stanard sleeve
              11.1" for Short Sleeve
              9.4" for Stanard sleeve (drive-up)
  • Weight:
              1248 lbs for UL safe
              1641 lbs for CEN safe
