MONITOR |
- 10.4" High Brightness LCD with
SVGA (800 x 600) resolution
- 8 menu keys
- Advertising capability
|
KEYPAD |
- 16-key alphanumeric keypad
- Encrypting PIN Pad (EPP)
- Triple DES compliant
|
PRINTER |
- 3 1/8" (80mm) thermal printer
- 100 mm/sec print speed
- Automatic paper loading and cutting
- Paper out sensor
- Graphics printing capability
|
CASH DISPENSER |
- Friction feed cash dispensing unit
(7 notes per second)
- Reject bin with key lock
- 1 cassette of 2000 note capacity
- Panel mounted for easy service
- Front loading for easy maintenance
- FCDU options:
- Configurable to hold up to 3 cassettes (2,000 note capacity each)
|
CARD READER |
|
SECURITY |
- UL 291 business hour listed safe
- Electronic lock
- Security options:
- UL291 Level 1 safe
- Cencon 2000 electronic lock
|
COMMUNICATION |
- 56k modem for dial-up connection
- Ethernet card for TCP/IP and LAN connectivity
|
VOICE GUIDANCE |
- Americans with Disability Act (ADA) compliant voice guidance
|
SOFTWARE |
- Microsoft® Windows® XP
- WOSA/XFS Compliant
- Electronic Journal using Disk On Chip technology
- Multi-language display
- Full-motion video capability
- Software options
|
HARDWARE |
- PC-based architecture
- 20 GB Hard Disk Drive (HDD)
- CD-ROM Drive
- x86 VIA C3 800 MHz processor
- 128MB RAM expandable to 256MB
- Disk On Chip (DOC)
- 2 PCI expansion slots
- 4 serial ports
- USB ports
- Hardware option
|
OPERATING ENVIRONMENT |
- Environment Temperature Range : 40F - 95F
- Relative Humidity: Non-condensing - 15% - 85%
|
DIMENSIONS |
- Height: 51"
- Width: 18"
- Depth: 22"
- Weight: 350 lbs
|
