| MONITOR |
- 7.4" color display with 640 x 480 resolution
|
| KEYPAD |
- 16 Keys alphanumeric Keypad
- PIN Encryption Device (PED) compliant
- Triple DES compliant
- 8 Function keys
|
| PRINTER |
- 3 1/8" (80mm) thermal graphics printer
- Direct thermal line printer with cut and push technology
- Print speed: 100mm/sec
|
| CASH DISPENSER |
- Dispenses 3.5 notes per second
- Cassette capacity: 1,000 notes
- Reject bin capacity: 30 notes
- Single Cassette
- High speed friction feed dispenser
|
| CARD READER |
|
| SECURITY |
- UL 291 Business Hours rated cabinet
- La Gard Combo electronic Lock
- Cencon Lock optional
|
| COMMUNICATION |
- Dial-up and TCP/IP connectivity solution
|
| SOFTWARE |
- Microsoft® Windows® CE
- Remote Management Software
- Performs Remote Diagnostics
- Receives & Archives Journals
- Graphic Images & Video clips transfer
- Software upgrades downloads
|
| HARDWARE |
- Geode GXI 200MHz
- 32MB RAM expandable to 128MB
- Compact Flash Disk
- 10/100 Ethernet
- Electronic Journal can store up to 10,000 transactions
- USB Camera optional
|
| OPERATING ENVIRONMENT |
- Environment Temperature Range:
50F - 100F
- Relative Humidity:
Non-condensing - 25% - 80%
- Power Consumption:
7A @ 115 VAC (ONLY) @ 50/60 Hz
|
| DIMENSIONS |
- Height: 51.18"
- Width: 17"
- Depth: 25.59"
- Weight: 286 lbs
|
